2.5T Forklift Paper Roll Clamp Long Reach Fork Accessories

Product Categories
Bonafe Technology Co., Ltd
Contact Now

2.5T Forklift Paper Roll Clamp Long Reach Fork Accessories

Brand Name : Bonafe

Place of Origin : China

MOQ : 1 Units

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000 Unit/Units per Year

Delivery Time : 5-8 work days

product category : Paper Roll Clamp

Material : Steel

Applicable Industries : Building Material Shops, Machinery Repair Shops, Energy & Mining, Manufacturing Plant, Food & Beverage Factory

Load capacity : 2800kg

Weight : 745kg

Roll range : 575-1400mm

Effective Thickness : 195mm

Short Arm Length : 624mm

Long Arm Thickness : 953mm

Contact Now

30G- Forklift paper roll clamp forklift accessories 2500kg 2550kg 2800kg


Parameter
2.5T Forklift Paper Roll Clamp Long Reach Fork Accessories

Capacity
(kg)		 Roll Range
(mm)		 Model No. Type Mounting Class Mounting Angle Long Arm Length
A (mm)		 Short Arm Length
B (mm)		 Long Arm Thickness
C (mm)		 Vertical Center
of Gravity
VCG		 Weight
(kg)		 Effective Thickness
ET (mm)		 Horizontal Center of Gravity
CGH (mm)
2800 575-1400 RCF30G-005B Fixed III 0° 953 624 43 429 745 195 268
2550 575-1525 RCF30G-007B Fixed III 0° 1005 695 43 429 765 195 286
2500 625-1600 RCF30G-009B Fixed III 0° 1098 739 43 429 785 195 287
2800 200-1400 RCF30G-006B Adjustable III 0° 953 624 43 429 763 195 268
2550 200-1525 RCF30G-008B Adjustable III 0° 1005 695 43 429 781 195 286
2500 200-1600 RCF30G-010B Adjustable III 0° 1098 739 43 429 798 195 287


Remark:.

1. Get the actual capacity of the stacker and accessories from the stacker manufacturer

2. If the stack operation is higher than 6800mm, use the "0" installation angle.

3. Provide non-standard rails where appropriate.




Hydraulic Flow&Pressure

Model Min.
Hydraulic
Flow(L/min)		 Rec.
Hydraulic
Flow(L/min)		 Max.
Hydraulic
Flow(L/min)		 Min.
Hydraulic
Pressure(Bar)		 Max.
Hydraulic
Pressure(Bar)
RC30F 20 40 60 35 160



Hydraulic Flow&Pressure

Model Rotator Speed Rotator Torque
RC30F 5.2r/min@57L/min 9000N.m@160Bar




Applicable Industries
Construction workshop, machinery repair workshop, energy and mining, manufacturing plant, food and drink factory


2.5T Forklift Paper Roll Clamp Long Reach Fork Accessories2.5T Forklift Paper Roll Clamp Long Reach Fork Accessories2.5T Forklift Paper Roll Clamp Long Reach Fork Accessories




Can be customized according to size

Customized solutions:
1. Carton Clamp
2. Block Clamp
3. Bale Clamp
4. Roll Clamp
......
all kinds of attachment
